Fuzrr FR2000C+ Clamp Ground Resistance Tester Product code: FR2000C+ Model: FR2000C+ Brand: Fuzrr Warranty Time: 2 Yıl REQUEST FOR SUBMISSION
Share:
Save Print
FR2000C+ clamp grounding resistance tester is a new generation of grounding resistance tester.
It adopts a new generation of LCD black screen backlight display and microprocessor technology.
It is convenient and quick to measure the grounding resistance. When measuring the grounding system with loop, there is no need to disconnect the grounding down-conductor or auxiliary electrode, which is safe and fast.
Widely used in telecommunications, electricity, meteorology, computer rooms, oil fields, power distribution lines, tower transmission lines, gas stations, factory grounding grids, lightning rods, etc.
The instrument has the characteristics of accurate, fast, simple, stable and reliable testing.
FR2000C+ clamp earth resistance tester is controlled by microprocessor, which can accurately detect earth resistance and leakage current. It uses fast filtering techniques to minimize interference. Store 300 sets of data at the same time.
General Technical Specifications
  • Resistance Range: 0 - 1200 Ω
  • Resistance resolution: 0.001Ω
  • Current Range: 0 - 20 A
  • Current resolution: 0.01mA
  • New black screen design, luxury
  • Ω + A same screen display
  • Quick self-test function without waiting
  • Using fast filtering technology, strong anti-interference ability
  • New design, long life clamp head
  • 300 sets of storage
  • Function: Ground resistance test, Loop resistance test, leakage current test
  • Power Supply: 4 section AA alkaline dry battery
  • Measurement Method: Mutual induction
  • Clamp Diameter: 55mm × 32mm
  • Display Mode: 4-digit LCD display, black screen design
  • LCD Dimension : 46mm × 29mm
  • Meter Dimension: W/T/H: 85mm × 58mm × 285mm
  • Sampling Speed About 2 times/second
  • Interference Test: Automatic identify interference signal, “NOISE” symbol indication when the interference current is large
  • Alarm Function: Alarm when the measured value exceeds the alarm setting value
  • Battery Voltage: Real-time display of battery power, reminding timely change when battery voltage is low
  • Automatic shut-down: “APO” instruction, automatic shutdown after 5 minutes boot
  • Power Consumption: 50mA Max
  • Weight: Instrument: 1180g (with battery)
  • Production Compliance: IEC61010-1 (CAT III 300V, CAT IV 150V, Pollution Grade 2); IEC61010-031; IEC61557-1
  • IP: IP45

Product code: FR2000C+
Save Print

Please contact us.


Save Print

Please look the file section for more technical info.


Downloadable Files Fuzrr FR2000C+ - Datasheet (397 kB)
